Planika – Insert fireplace – FORMA 1000 IS WITH FLA4 790

Name: Forma 1000 Insert FLA4 790 Burner | Bentley Bioethanol Fires
Price: 6605.00 GBP
Availability: InStock

Planika - Insert fireplace - FORMA 1000 IS WITH FLA4 790

Details

approx. VIEWING AREA
see technical sheet for specific dimensions)
W: 1016 mm / 40”
H: 508 mm / 20”
D: 406 mm / 16”

£6,605.00

Have a question? Ask before you buy

Delivery within 14 days

Dependent on stock. Most products are built and shipped directly from the factory.

The Planika Forma 1000 Island Fireplace Insert with FLA4 790 is a four-sided open island bioethanol firebox. The non-combustible steel housing surrounds the FLA4 790 BEV burner with tempered glass on every visible side, ready to drop into a freestanding feature wall or central island feature. No flue, no chimney, no construction work, just a 230 V plug.

Key features

Four-sided island flame: See the fire from every angle.
FLA4 790 burner: Up to 8 hours per fill with 6-stage flame regulation.
BEV Technology: Vaporised ethanol burns clean with no soot or ash.
Zero-clearance housing: Approved for installation in flammable materials.
Glass screens included: Tempered glass on all four visible sides.
Plug & Play: 230 V supply only, no flue or chimney.

BEV (Bio Ethanol Ventless) is Planika’s patented automatic burner technology. Bioethanol is heated inside a sealed chamber and turned into flammable vapours, so it is the vapour that burns, never the liquid fuel itself. A microprocessor regulates combustion and a suite of safety sensors (temperature, fuel level, seismic, spillage) monitor the burn at all times.

Combustion is clean with no smoke, soot or ash, so the fireplace produces real flame and warmth without flue or chimney requirements.

Configuration	Island (four-sided open)
Forma length	1000 mm
Burner	FLA4 790
Fuel type	Bioethanol 95–96.6%
Fuel tank capacity	3.1–14.8 L
Burning time	Up to 8 hours
Flame regulation	6 stages
Power supply	230 V
Materials	Non-combustible galvanised steel housing, toughened glass
Finish	Black powder coating
Application	Indoor use only
Flue / chimney	Not required

Forma 1000 Island firebox housing
FLA4 790 BEV burner
Four tempered glass screens
Automatic refuelling pump
Remote control
Power cable
Mounting hardware
Installation and user manual

Finish:

Black powder coating as standard
Custom RAL colours available on request

Power supply:

UK (BS 1363) plug as standard
EU (Schuko) plug available on request

What does this kit include?

The kit includes the Forma 1000 Island firebox housing with the FLA4 790 BEV burner, tempered glass screens for all four visible sides, automatic refuelling pump, remote control, power cable and mounting hardware.

Do I need a flue or chimney?

No. The Forma 1000 Island uses BEV ventless technology and only needs a 230 V plug socket.

How long does one fill of fuel last?

The FLA4 790 delivers up to 8 hours of burn time on the lower flame setting; less on higher settings. Refilling is automatic via the integrated pump.

Can I install it as a central feature?

Yes, the four-sided island configuration is designed for centre-of-room installation in a feature wall, divider or freestanding plinth. The housing is non-combustible, so framing materials can be timber or plasterboard.

What fuel does it use?

Use high-grade bioethanol fuel (95–96.6% concentration). We recommend Calida Premium Bioethanol Fuel for warranty and clean burn.

Is professional installation required?

Recommended. The Forma 1000 Island is designed for installation by a competent installer or experienced trade. Bentley Bioethanol Fires UK can supply only or arrange an assisted installation.
